Self - Lubricating DLC Coating Machine / Hard Coating Machine For Hard Tools Drills

ATOP Hard Tools Drills Hard Film DLC Coating Vacuum Plating Machine

1. The vacuum system: mechanical pump, rotary vane pump, roots pump, molecular pump, cryogenic

pump, with cold trap of high vacuum oil diffusion pump large pumping speed extraction system, the

backing pump optional oil-free vacuum pumps, stainless steel pipes and valves.

2. The coating system: adopting multiple sets of intermediate frequency magnetron sputtering power

supply, with 1-2 of the unbalanced magnetron target, and is equipped with 6-14 hot cathode arc, and the

arc power supply, dc superposition pulsed bias power supply, the international leading level of arc source

and anode layer ion source;Equipped with 1-2 sets of original imported off-loading source.

3. Inflating system: automatic gas flowmeter and flow display instrument control.

4. Control system: color touch screen, PLC, automatic and manual control can be converted at any

time.Real-time display detailed parameters, fully automatic control of the entire production process,

automatic storage process parameters.The main electrical components are famous brands such as

schneider.

5. Safety system: setting up the sound and light alarm device of water, electricity and gas anomaly, and

implementing corresponding protection procedures.

6. Heating and baking system: adopt stainless steel tube heating body, the base plate temperature can

reach 300 degrees, the temperature control meter adopts the Japanese conductive instrument, the

temperature control precision is plus or minus 1 degree Celsius.

7. Control system: real-time display detailed parameters, fully automatic control of the entire production

process, and automatic storage of process parameters.



1.Plasma source assisted deposition technology,pre-cleaning and the auxiliary deposition to the work

piece.


2. Adopt the high power pulse bias power supply enhance the coating adhesion.


3. Adopt multiple sets of twin arc,which can install 2-6 different target materials.Pure metal or alloy

composite nano film layer is achieved.


4.The work piece rack adopts rotation and revolution structure,large loading capacity and temperature

resistance.The frame can move out of the chamber which is convenient to load heavy molds.The work

piece rack can be customized according to customer requirements and adopts inverter to adjust,and

infinitely adjustable speed.
