Product Details:
Payment & Shipping Terms:
|
| Substrate: | Hardware,glass Crafts,ceramic Crafts,etc | Coating Film: | Function Film,decorative Film,etc |
|---|---|---|---|
| Coating Color: | Gold,rose Gold,brown,bronze,blue,black,etc | After Sale Service: | Engineers Avaliable To Service Machinery Oversea |
| Limited Vacuum Degree: | 8*10-4Pa | Technology: | Vacuum Coating |
1. It equipments cryogenic ion secondary source, some substrate without heating the material, It
can directly do the cold plating film at room temperature, save energy, increase productivity.
2. The maximum of the temperature for tool coating chamber can 600 degrees, In addition to the tool
Coater coating applications require heating device, other applications do not need the device.
3. High deposition rate, High coating speed, It can be widely used to do the decorative coating, functional
coating on a variety of products. So it is a ideal equipment to do the high-grade and best coating for mass
production.
4. Magnetron sputtering principle is based on the theory of the cathode glow discharge, it expend the
cathode surface magnetic field near the work piece surface. Then it improves the sputtered atom
ionization rate. It keeps the magnetron sputtering uniformity, also can improve the surface shining effect.
5. The arc plasma evaporation source is reliable, it can work under 40A current in optimizing the cathode
and the magnetic field structure,. It will happen atomic diffusion between the coating and the material. It
also has the advantages that lon Beam Assisted Deposition.
6. Vacuum pumping system, electric control system and complete vacuum coating system can be
customized according to user requirements.
Product Name |
ATOP Immitation Gold Jewelry PVD Vacuum Coating Ion Plating Machine
|
Vacuum Chamber Size |
Decide according to the substrate size and output |
| Substrate | Hardware,glass crafts,ceramic crafts,such us watches,mobile phone metal shell,sanitary ware,mould,electronic products,crystal glass, glasses, cutlery, knives and so on |
Coating Film |
High-grade decorative coating. |
| Coating Color | Gold, rose gold,coffee,brown,bronze,blue,black,white,gray etc. |
| Applications | Hardware,glass crafts,ceramic crafts such us watches,mobile phone metal shell,sanitary ware,mould,electronic products,crystal glass, glasses, cutlery,knives and so on. |
| Structure | Vertical type ; horizontal type ; single door type ; double-door type. |
| Coating Material | Stainless steel, aluminum, titanium, tungsten and other metal films may be manufactured as coated TIN, TIC, TICN, TIALN, CRN, CU, AU, diamond film (DLC), decorative film metal, film and non-metallic composite coating film and its compounds film. |
| Features | High pumping speed, high efficiency, energy saving, full automatic process controller can be simple, reliable, beautiful. |
Vacuum coating machine is the most environmental and friendly surface treatment machine without waste
and harmful gas and liquid.
The specific configuration of coating machine can be designed according to process requirements of
coating products.
Vacuum coating machine make the metal deposition on surface of the product,make the it colorful,
beautiful,function Strong adhesion , good compactness, well repeatability and consistence of color.
Structure type:Vertical type or horizontal type
Chamber type:single door or double doors
It applies to hardware,glass crafts,ceramic crafts,such us watches,mobile phone metal shell,sanitary
ware,mould,electronic products,crystal glass, glasses, cutlery, knives and so on.
You can make super-hard wear-resistant film coating, anti-corrosion film, decorative film(gold color,rose
gold,coffee,brown,bronze,blue,black,white,gray and other colors),it combined with magnetron sputtering
technique can be plated the multilayer composite membrane and manufactured plated stainless steel,
aluminum, titanium, tungsten and other metal films may be manufactured as coated TIN, TIC, TICN, TIALN,
CRN, CU, AU, diamond film (DLC), decorative film metal, film and non-metallic composite coating film and
its compounds film.
